Shielding Fabrics

SwissShield Daylite

Please call (925) 937-1754 or email us for pricing if it’s not specified.  Some prices may vary depending upon foreign exchange rate, as one of our suppliers is located in Canada.

SwissShield Daylite Fabric

SwissShield Daylite – Shielding Fabric

Daylite is a highly transparent, open mesh fabric with excellent air and light penetration. Very light weight and perfect for canopies, window curtains, and head coverings. Using polyester for strength, with 7.5% copper, 0.5% silver filament in the yarn. Washable, white mesh, 8.2 feet wide.

Technical data
• Attenuation: 20 dB at 1 GHz
• Color: White
• Raw materials: 92% polyester, 7.5% copper, 0.5% silver
• Weight: 65 g/m²
• Dimension stability: 0.1-0.3%
• Low conductivity surface, cannot be grounded
• Resistivity: 1010 Ohm/sq
• Extremely wide format (about 102 inches/8.5 feet wide)
• Cut edges are fray-resistant

Washing instructions:
• Machine Washable- Gentle Cycle – Cold Water
• Recommend hand washing
• Hang to dry
• Do not tumble dry
• Can be ironed on low setting
• No bleaching
• No chemical dry cleaning

NOTE: Regardless of which Swiss Shield® fabric you choose, it is still important to follow the complete range of safety guidelines which will guarantee that the product will provide you with optimum performance.

• When the Swiss Shield® fabric is installed, its location, quantity and proper installation is best determined by a trained EMF specialist. This fabric will reflect radio frequency radiation and improper installation can result in increased exposure.

• In order to ensure optimum screening performance, the sleeping space should be assessed for radio frequency radiation and AC electric fields. Before and after measurements are important to determine the overall effectiveness of the shield.

• We do not recommend grounding the fabric because it is not externally conductive

• Do not use electronic or electrical devices near or under the fabric.

• Swiss Shield® fabric is not fire retardant. Use with caution and at your own risk.

• Swiss Shield® fabric is intended exclusively for indoor use in dry areas.

SwissShield Daylite… sold by the linear foot

________________________

SwissShield Naturell

Naturell Fabric

SwissShield Naturell Fabric

Naturell is a translucent, unbleached ecological cotton fabric. Typical application as canopies, clothing, curtains or drapes.
• Ecological cotton fabric without chemicals
• Highest attenuation of the 3 SwissShield materials
• Washable, easy to iron, cut and sew
• Low conductivity surface, cannot be easily grounded
• Resistivity: 106 Ohm/sq
• Extremely wide format (about 98 inches/ 8.2 feet wide)

Technical data
• Attenuation: 38 dB at 1 GHz
• Color: Ecru-White
• Raw materials: 82% cotton, 17% copper, 1% silver
• Weight: 69 g/m²
• Dimension stability: 3%
• Certificates: Öko-Tex 100 Class 1 (gentle enough for baby underwear)

Naturell Shielding Perf

Naturell Shielding Performance Chart

Washing instructions:
• Machine Washable- Gentle Cycle – Cold Water
• Recommend hand washing
• Hang to dry
• Do not tumble dry
• Can be ironed on low setting
• No bleaching
• No chemical dry cleaning

Swiss Shield Naturell……..sold by the linear foot

________________________



Ex-Static™ Conductive Fabric

Ex-Static Fabric

Ex-Static™ Conductive Fabric

Excellent for Static Discharge and Grounding
A light weight, durable conductive fabric. 87% polyester, 13% gray BASF Resistat (carbon) fibers woven right into the fabric in an attractive diamond pattern providing surface resistivity of 105 Ohms per square. Very comfortable, only 3 oz per square yard, it cuts, sews, and washes like any polyester fabric! Conductivity will hold up to 50 or more low heat washings. Can be used to make grounded surfaces, appliance covers, clothing, drapes, room dividers, and anything else you can sew. Color is white with gray diamond pattern.





Thickness:
Width: 64 inches
Weight: 3.2 oz/yd²
Resistivity: 105 Ohms per square
Color: White with grid pattern
Base: Polyester
Conductor: Carbon threads

Washing instructions:
• Machine Washable- Gentle Cycle – Cold Water
• Recommend hand washing
• Hang to dry
• Do not tumble dry
• Can be ironed on low setting
• No bleaching
• No chemical dry cleaning

Ex-Static Fabric – sold by the linear foot. (Part. #A1209) …………… $4.95

Buy It Online
